Description
SPECS
Manufacture Model
AS-22UW4SBBTD
Type Of AC
Heat pump
RATINGS
Cooling Capacity
6500(2300-7900)
Heating Capacity
6600(2100-9000)
Power Input-Cooling
1980(600-3000)
Power Input-Heating
1920(600-3300)
Moisture Removal
2.5
Air Circulation
1150
EER
3.28282828282828
COP
3.4375
Energy Class for Argentina (Cooling)
A
Energy Class for Argentina (Heating)
A+
Refrigerant
R410A
Refrigerant volumn
1670
Unit Noise Level
INDOOR: (HIGH) = 48, (LOW) = 40 / OUTDOOR: 58
POWER SUPPLY
Voltage, Frequency, Phase
220-240V~,50Hz,1P
Rated Current Cooling (A)
9.2
Rated Current Heating (A)
8.9
LRA
–
SYSTEM
Compressor type
Rotary
Compressor Model No.
ATF235D22UMT
Compressor MFG
GMCC
Expansion Device
Flow restrictor
Evaporator
Copper tube and Aluminum Fin
Condenser
Copper tube and Aluminum Fin
CONNECTING PIPE DIAMETER
Liquid Pipe (inch)
3/8
Gas Pipe (inch)
5/8
Maximum connection pipe length
15
Maximum height difference
5
FEATURES
Display on Front Panel
LED
LCD Wireless Remote Controller
Yes
Removable and washable Panel
Yes
Active Charcoal Filter
Optional
Electrostatic Filter
Optional
LTC Filter
Optional
Catechin filter
Optional
Negative ion filter
Optional
Photic Catalyst filter
Optional
Vitamin-C filter
Optional
Dimmer
Yes
24 Hours Timer
Yes
Timer ON/OFF
Yes
5 Speed and Auto Indoor Fan Control
Yes
Silent Mode
Yes
Horizontal Auto Swing Louver
Yes
Manual Adjustable Vertical Louver
Yes
Top Down Horizontal louvers features for cooling mode
Yes
Sleep function
Yes
Smart sense function
Yes
Super function
Yes
Compressor Indicator
Yes
Auto Restart
Yes
Auto Defrost
Yes
Dehumidification function
Yes
Cold air protection
Yes
FILTER INFORMATION
Washable PP filter
Yes
HEPA Filter
Optional
DIMENSIONS
Net Dimensions – WxHxD (mm) Indoor Unit
1131×315×230
Net Dimensions – WxHxD (mm) Outdoor Unit
860x650x310
Net Weight (Kg) Indoor Unit
14.5
Net Weight (Kg) Outdoor Unit
47
Packing Dimensions WxHxD (mm) Indoor Unit
1220×400×310
Packing Dimensions WxHxD (mm) Outdoor Unit
995x730x445
Gross Weight (Kg) Indoor Unit
17
Gross Weight (Kg) Outdoor Unit
51
Loading Capacity (20’/40’/40’HC ) without pipe
60/128/144
Loading Capacity (20’/40’/40’HC ) with pipe
60/128/144
Approvals
CB
